Why Namespace SSH Credentials with Git?

Why would you ever want to namespace your SSH credentials with Git? If you have multiple accounts on the same Git hosting service, you might want to use different SSH keys for each account. This is a common scenario for developers who have both personal and work accounts on GitHub, GitLab, or Bitbucket. This post will show you how to set up SSH namespaces with Git, so you can use different SSH keys for different accounts on various hosting services.

Overview

To successfully namespace SSH credentials with Git required several steps. Before we detail these steps, let’s first look at the high-level overview of the process. We begin by explaining the meaning of a ssh namespace, then outline the general flow of the process, including the call stack layers of both git and ssh. If you want to skip this overview and begin setting up your namespaces, you can jump to the next section.

SSH Namespaces

An SSH namespace is essentially a description of which SSH keys to use for which repositories. Specifically, it is a combination of:

• A git host (e.g. github.com, gitlab.com, bitbucket.org)
• A namespace within that host (e.g. a username or organization name)
• An SSH key to use for that namespace
• One or more repositories within that namespace
• A local directory containing all the relevant repositories

General Flow of Git and SSH

The general flow of the process is outlined in the diagram below. It begins with a call to git, which then uses configuration files to determine a namespace. This namespace is then used to determine how to modify the url for the subsequent call to ssh. The ssh call then uses the url to determine which key to use.

Where the numbered steps correspond to the steps in the following section.

Setting Up Namespaces: 4 Steps

For this walkthrough, we will implement 3 namespaces, two for GitHub and one for GitLab. All source code will be stored locally under the ~/code directory, under which we will create subdirectories for each namespace.

Step 0: Prerequisites

Before we begin, we need to establish the context for the 3 namespaces. We will use the following as examples of the Host/Account/Email/Repo combinations that might motivate the use of namespaces:

• Name: personal
  • Host: GitHub
  • Account: personal
  • Email: personal@email.com
  • Repos: repo1 and repo2
• Name: work
  • Host: GitHub
  • Account: organization
  • Email: work@email.com
  • Repos: repo3 and repo4
• Name: collab
  • Host: GitLab
  • Account: collab
  • Email: collab@email.com
  • Repos: repo5 and repo6

Step 1: Create SSH Keys and Add to Hosts

First, we need to create SSH keys for each namespace. We will create 3 keys, one for each namespace. We will use the default names for the keys, id_ed25519_{name} and id_ed25519_{name}.pub, and store them in the default location, ~/.ssh. For creating the keys, we can use the following commands:

1

ssh-keygen -t ed25519 -C "{email}" -f ~/.ssh/id_ed25519_{name}

Where {email} is the email associated with the namespace. For example, for the personal namespace, we would use:

1

ssh-keygen -t ed25519 -C "personal@email.com" -f ~/.ssh/id_ed25519_personal

Make sure that these keys are added to the appropriate host. The GitHub and GitLab documentation provide instructions for adding SSH keys to your account ^{1 2}.

Step 2: SSH Key Routing

Next, we need to create an SSH config file to route the namespaces to the appropriate keys. We will create a file at ~/.ssh/config with the following contents:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

Host github.com-organization
HostName github.com
UseKeychain yes
AddKeysToAgent yes
User git
IdentityFile ~/.ssh/id_ed25519_work
IdentitiesOnly yes

Host github.com-personal
HostName github.com
UseKeychain yes
AddKeysToAgent yes
User git
IdentityFile ~/.ssh/id_ed25519_personal
IdentitiesOnly yes

Host gitlab.com-collab
HostName gitlab.com
UseKeychain yes
AddKeysToAgent yes
User git
IdentityFile ~/.ssh/id_ed25519_collab
IdentitiesOnly yes

This file tells SSH to use the appropriate key for each namespace. The Host lines define the namespace, and the IdentityFile lines define the key to use for that namespace. The IdentitiesOnly line tells SSH to only use the specified key for that namespace. We will use git url modification to route the namespaces to the appropriate host.

Step 3: Git Namespace Configs

Next, we need to tell git how to configure each namespace. This is achieved by creating a .gitconfig file in the root directory of each namespace. Specific examples are provided below for the three namespaces in this walkthrough.

The file ~/code/personal/.gitconfig should contain the following:

1
2
3
4
5

[user]
  email = personal@email.com

[url "git@github.com-personal"]
  insteadOf = git@github.com

The file ~/code/work/.gitconfig should contain the following:

1
2
3
4
5

[user]
  email = work@email.com

[url "git@github.com-organization"]
  insteadOf = git@github.com

The file ~/code/collab/.gitconfig should contain the following:

1
2
3
4
5

[user]
  email = collab@email.com

[url "git@gitlab.com-collab"]
  insteadOf = git@gitlab.com

These files tell git to modify the host name for each namespace. The user section specifies the email to use for each namespace, and the url section specifies the namespace and the host to use for that namespace. We need one more step, though, to make this work.

Step 4: Git Namespace Routing

The final step is to tell git to use the ~/code/{name}/.gitconfig files for each namespace. This is achieved by modifying the overall ~/.gitconfig file to include the following:

1
2
3
4
5
6
7
8

[includeif "gitdir:~/code/personal/"]
	path = ~/code/personal/.gitconfig

[includeif "gitdir:~/code/work/"]
	path = ~/code/work/.gitconfig

[includeif "gitdir:~/code/collab/"]
	path = ~/code/collab/.gitconfig

This tells git to use the appropriate .gitconfig file for each namespace. The includeif lines specify the directory to use for each namespace, and the path lines specify the .gitconfig file to use for that namespace.

Using Namespaces

Once the namespaces are set up, you can use them as you would use any other git repository. For example, to clone a repository in the personal namespace, you would use the following command:

1
2
3
4
5
6

# Change working directory
cd ~/code/personal

# Clone repository
# Clone repository
git clone git@github.com:personal/repo1.git

Thats it! You should now be able to use different SSH keys for different accounts on the same Git hosting service.

References

This post was adapted from and inspired by several sources, with a few key changes and summary ^{3 4 5}.
